About the IS230TICIH3A
The IS230TICIH3A is a Contact Input Module from the Mark VIe Series. This module was manufactured by GE Energy. The IS230TICIH3A is made up of an IS200TICI terminal board and up to three PDIA I/O packs, depending on the application being used.
IS230TICIH3A Specifications
The IS230TICIH3A has 24 point isolated voltage detection circuits. These circuits are designed to sense a range of voltages in several hardware types. The circuits can be used with:
- Switches
- Fuses
- Relay contacts
There is no contact excitation on the IS230TICIH3A terminal board. Each input is also electronically isolated from all other inputs and active electronics. The IS230TICIH3A offers several diagnostic features that allow users to monitor the status of the module and its components.
