About the IS230TICIH1A
The IS230TICIH1A is a Contact Input Module that was manufactured by GE Energy. This module was manufactured for use in the Mark VIe Series. The IS230TICIH1A is comprised of an IS200TICI terminal board and up to three PDIA I/O packs.
IS230TICIH1A Specifications
The IS230TICIH1A provides 24 point isolated voltage detection circuits. These circuits are used to sense a range of voltage across a number of components. These components include:
- Relay contacts
- Fuses
- Switches
The IS230TICIH1A can be used in simplex, dual, and TMR applications. This means that one to three I/O packs will be used with the module, depending on the application. There are no jumpers on the IS230TICIH1A, which means that the module cannot be configured.
