The IS230TDBTH2A is a Discrete I/O Module from the Mark VIe Series that was manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TDBTH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TDBTH2A
SKU: GBTC-58854

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TDBTH2A Technical Specifications

Part Number	IS230TDBTH2A
Product Type	Discrete I/O Module
Manufacturer	GE Energy
Series	Mark VIe
Revision Quantity	One Mark VIe/S Revision
Functional Revision	A-Rated
Total Number I/O Packs	3 Packs
I/O Packs	PDIO

About the IS230TDBTH2A

The IS230TDBTH2A is a Discrete I/O Module that was manufactured by GE Energy. This module was designed to be used in the Mark VIe Series. The IS230TDBTH2A is comprised of an IS200TDBT terminal board and three PDIO I/O Packs.

IS230TDBTH2A Specifications

The IS230TDBTH2A accepts 24 group isolated contact inputs and has a 24 V dc wetting voltage rating. This voltage is provided from an external source for the contact inputs.

The IS230TDBTH2A works in TMR applications, which means that three PDIO packs are required for the module. These packs will connect to the board using the following connectors:

JT1 Connector
JS1 Connector
JR1 Connector

The IS230TDBTH2A can be used with one option board, the IS200WROB. This module is not compatible with WROF and WROG option boards.

Frequently Asked Questions about IS230TDBTH2A

What does the WROB option board provide for the IS230TDBTH2A?

The WROB option board provides fused and sensed relays to the first six outputs of the IS230TDBTH2A and dedicated power to the last relay output.

Does the IS230TDBTH2A have any diagnostic features?

Yes, the IS230TDBTH2A has several diagnostic features. One of these is wetting voltage monitoring, which will create a fault if the wetting voltage goes below 40% of the nominal voltage.
