Can the outputs be configured on the IS230TBAOH1C?

No, the outputs cannot be configured on the IS230TBAOH1C because there are no jumpers.

How are current outputs generated on the IS230TBAOH1C?

Current outputs on the IS230TBAOH1C are generated by the I/O processor.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home GE Boards & Turbine Control Mark VIe & Mark VIeS Control Systems IS230TBAOH1C

❮

❯

About | Product Specifications | FAQs

IS230TBAOH1C

4.93 (14)
Click a star to rate this product

4.93 (14)
Click a star to rate this product

The IS230TBAOH1C is an Analog Output Module from the Mark VIe Series that was manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TBAOH1C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TBAOH1C
SKU: GBTC-58808

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TBAOH1C Technical Specifications

Part Number	IS230TBAOH1C
Product Type	Analog Output Module
Manufacturer	GE Energy
Series	Mark VIe
I/O Packs Impacted	1 PAOC Pack
TMR/Simplex Rating	Simplex
Mounting Strategy	DIN Rail + Corresponding Bracket

About the IS230TBAOH1C

The IS230TBAOH1C is an Analog Output Module from the Mark VIe Series. This module was manufactured by GE Energy. The IS230TBAOH1C is comprised of an IS200TBAO terminal board and a PAOC I/O Pack.

IS230TBAOH1C Specifications

The IS230TBAOH1C supports 16 analog outputs that have a current range of 0-20 mA. The IS230TBAOH1C only supports simplex applications, which means that only one PAOC pack will be used with the module.

There are several diagnostic tests that the IS230TBAOH1C runs. These are:

Hardware compatibility test
Unhealthy analog output test

The I/O pack connects to the TBAO board through the D-type connector and communicates with the controller over Ethernet.

Reviews For IS230TBAOH1C

Internal Review

(5.0)

The IS230TBAOH1C has noise suppressants and filters that protect the outputs from surge and high frequency noise. This is an important feature of the module. The IS230TBAOH1C cannot be used in TMR systems, which means the module is only used for simplex systems. - AX Control Lead Technician
