IS230TBAIH1C

4.92 (13)
Click a star to rate this product

4.92 (13)
Click a star to rate this product

The IS230TBAIH1C is an Analog I/O Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230TBAIH1C to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230TBAIH1C
SKU: GBTC-58798

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230TBAIH1C Technical Specifications

Part Number	IS230TBAIH1C
Product Type	Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
Input Signal Style	Analog I/O
Isolation Status	Not Isolated
Mounting	Typical DIN-Rail
Redundancy	Simplex Redundancy

About the IS230TBAIH1C

The IS230TBAIH1C is an Analog Input/Output Module that was manufactured by GE Energy for use in the Mark VIe Series. The IS230TBAIH1C is made up of an IS200TBAI board and a PAIC I/O pack. The IS230TBAIH1C can be used in either simplex or TMR systems.

IS230TBAIH1C Specifications

The IS230TBAIH1C supports 10 analog inputs and 2 outputs. The inputs can support two, three, or four wire transmitters, in addition to externally powered transmitters.

The analog outputs have multiple ranges of currents. These are:

0-20 mA
0-200 mA

The IS230TBAIH1C can be used in TMR systems, which means that three PAIC packs can be fitted to the terminal board.

Frequently Asked Questions about IS230TBAIH1C

What kind of diagnostic testing does the IS230TBAIH1C have?

The IS230TBAIH1C has a diagnostic test for compatibility with the terminal board and a check for unhealthy outputs.

Does the IS230TBAIH1C act as a power source?

The TBAI terminal board on the IS230TBAIH1C acts as a power source for transducers. The board can give 24 V dc power.

Reviews For IS230TBAIH1C

Internal Review

(5.0)

The IS230TBAIH1C can be used in TMR systems, in addition to simplex systems. This allows for three PAIC packs to be used at a time. The IS230TBAIH1C also allows for a variety of transmitters to be used with the inputs. - AX Control Lead Technician

Repair Services For IS230TBAIH1C

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	Ask	Get Quote

Our highly skilled technicians can repair your IS230TBAIH1C. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year
