What type of mounting device does the IS230STCIH4A use?

The IS230STCIH4A can be DIN rail mounted.

What is the threshold voltage for the IS230STCIH4A?

The IS230STCIH4A has a threshold voltage of 50% of the excitation voltage.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home GE Boards & Turbine Control Mark VIe & Mark VIeS Control Systems IS230STCIH4A

About | Product Specifications | FAQs

IS230STCIH4A

4.00 (1)
Click a star to rate this product

4.00 (1)
Click a star to rate this product

The IS230STCIH4A is a Discrete Input Module manufactured by GE Energy for use in the Mark VIe Series

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230STCIH4A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230STCIH4A
SKU: GBTC-58818

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230STCIH4A Technical Specifications

Part Number	IS230STCIH4A
Product Type	Discrete Input Module
Manufacturer	GE Energy
Series	Mark VIe
Input Signal Style	Discrete
Signals Accepted	Input Only
Personal Input/Output Pack	PDIA
V DC	48 V DC

About the IS230STCIH4A

The IS230STCIH4A is a Discrete Input Module that was manufactured by GE Energy for use in the Mark VIe Series. The IS230STCIH4A is made up of an IS200STCI board and a PDIA I/O pack.

IS230STCIH4A Specifications

The IS230STCIH4A accepts 24 contact inputs and has an excitation voltage of 48 V dc. The PDIA pack plugs into the D-type connector on the IS200STCI board and communicates with the controller over Ethernet.

There are several diagnostic tests that the PDIA pack has for the board. These are:

Contact excitation voltage monitoring
Periodic tests of all contact inputs
On board ID check by the I/O pack

The ID check is used to determine compatibility between the board and the I/O pack.

Reviews For IS230STCIH4A

Internal Review

(4.0)

The IS230STCIH4A has the same function and on board signal conditioning as those on the TBCI terminal board. The IS230STCIH4A has a pluggable type terminal strip, which allows users to take the strip on and off. The IS230STCIH4A also has filters that reduce high frequency noise. - AX Control Lead Technician
