IS230SNSCH2A

5.00 (1)
Click a star to rate this product

5.00 (1)
Click a star to rate this product

The IS230SNSCH2A is a Serial Communication Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230SNSCH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230SNSCH2A
SKU: GBTC-59498

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230SNSCH2A Technical Specifications

Part Number	IS230SNSCH2A
Product Type	Serial Communication Module
Manufacturer	GE Energy
Series	Mark VIe Series
I/O Pack Redundancy	Simplex Redundancy
I/O Pack	PSCA
Terminal Board	IS200SSCAH2A
Communication Channels	6 Channels

About the IS230SNSCH2A

The IS230SNSCH2A is a Serial Communication Module that was manufactured by GE Energy. This module was designed to be used within the Mark VIe Series of Turbine Controls. The IS230SNSCH2A consists of an IS200SSCA terminal board and one PSCA I/O Pack.

IS230SNSCH2A Specifications

The IS230SNSCH2A provides up to six communication channels. Each channel can be configured to work with the following signals:

RS-232C
RS-422
RS-485

The IS230SNSCH2A has a simplex redundancy, which means that only one PSCA pack will be used in its configuration. This pack plugs into the DC-37 pin connector. The PSCA pack can communicate with the controller it is being used with over Ethernet.

Frequently Asked Questions about IS230SNSCH2A

How are the signals on the IS230SNSCH2A arranged?

The signals on the IS230SNSCH2A are arranged as SCOM, A, B, C, D, and RET.

Does the IS230SNSCH2A have a pluggable terminal strip?

The IS230SNSCH2A has a right angle header that allow for terminal strips to be plugged into the board, accepting 48 terminals.

Reviews For IS230SNSCH2A

Internal Review

(5.0)

The IS230SNSCH2A is designed to be used as a Serial Communications Module. This module can only be used in simplex systems, which means only one I/O pack is required. The IS230SNSCH2A can be configured using the jumpers on the terminal board. - AX Control Lead Technician
