Is the IS230SNIAH2A compatible with the YAIC pack?

No, the IS230SNIAH2A is not compatible with the YAIC because that pack is from the Mark VIeS Series.

How many terminals does the IS230SNIAH2A have?

The IS230SNIAH2A has 48 terminals and has a Euro block terminal block for these.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home GE Boards & Turbine Control Mark VIe & Mark VIeS Control Systems IS230SNIAH2A

About | Product Specifications | FAQs

IS230SNIAH2A

4.93 (14)
Click a star to rate this product

4.93 (14)
Click a star to rate this product

The IS230SNIAH2A is an Isolated Analog I/O Module that was manufactured by GE Energy for the Mark VIe Series

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230SNIAH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230SNIAH2A
SKU: GBTC-58794

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230SNIAH2A Technical Specifications

Part Number	IS230SNIAH2A
Product Type	Isolated Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
I/O Pack Redundancy	Simplex Redundancy
I/O Packs Impacted	PAIC
Assembly Type	Modular; Standard
Terminal Board	IS200SAII

About the IS230SNIAH2A

The IS230SNIAH2A is an Isolated Analog Input from the Mark VIe Series. This module was manufactured by GE Energy. The IS230SNIAH2A consists of an IS200SAII terminal board and a PAIC I/O Pack.

IS230SNIAH2A Specifications

The IS230SNIAH2A accepts 10 analog inputs and 2 analog outputs through its terminal board. The PAIC pack connects to the board using the D-type connector. This pack communicates with the controller over Ethernet. The analog outputs can accommodate multiple types of transmitters. These transmitters are:

Externally powered transmitters
2-wire transmitters
3-wire transmitters
4-wire transmitters

The analog inputs each have an isolator with a rating of 1500 V rms. The analog outputs have a current rating of 0-20 mA.

Reviews For IS230SNIAH2A

Internal Review

(5.0)

The IS230SNIAH2A is able to be configured through the PAICH2 pack. This configuration allows one of the analog outputs to have a current rating of 0-200 mA instead of 0-20 mA. This configuration can only be made using the PAICH2 I/O pack. - AX Control Lead Technician
