What type of terminal blocks does the IS230SNHRH2A have?

The IS230SNHRH2A has high density Euro block type terminal blocks.

How much power is available on the terminal board?

The terminal board offers 24 V dc power for the transmitters.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home GE Boards & Turbine Control Mark VIe & Mark VIeS Control Systems IS230SNHRH2A

❮

❯

About | Product Specifications | FAQs

IS230SNHRH2A

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The IS230SNHRH2A is a HART Analog I/O Module from the Mark VIe Series by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230SNHRH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230SNHRH2A
SKU: GBTC-58876

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230SNHRH2A Technical Specifications

Part Number	IS230SNHRH2A
Product Type	HART Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
HART Product Status	HART Enabled
Terminal Board	IS200SHRA
Mounting Apparatus	Back-Placed Mounting Bracket
Revision Total	One A-Rated Rev

About the IS230SNHRH2A

The IS230SNHRH2A is a HART Enabled Analog Input/Output Module from the Mark VIe Series. This module was manufactured by GE Energy. The IS230SNHRH2A is made up of an IS200SHRA terminal board and a PHRA I/O pack.

IS230SNHRH2A Specifications

The IS230SNHRH2A accepts 10 analog inputs and 2 analog outputs. The analog inputs can accommodate several types of transmitters. These are:

2-wire transmitters
3-wire transmitters
4-wire transmitters
Externally powered transmitters

The IS230SNHRH2A allows HART messages to pass between the PHRA pack and a HART enabled field device. There is an on board ID chip on the IS200SHRA terminal board that identifies the board to the PHRA pack for system diagnostic purposes.

Reviews For IS230SNHRH2A

Internal Review

(5.0)

The IS230SNHRH2A has several diagnostic tests available that can help if there is something wrong with the terminal board. One of the tests checks the output current and the I/O pack will send a diagnostic alarm if one of the outputs goes unhealthy. The output being unhealthy will cause problems for the IS230SNHRH2A. - AX Control Lead Technician
