The IS230SNCIH2A is a Contact Input Module manufactured by GE Energy for the Mark VIe Series

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230SNCIH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230SNCIH2A
SKU: GBTC-58816

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230SNCIH2A Technical Specifications

Product Number	IS230SNCIH2A
Product Type	Contact Input Module
Manufacturer	GE Energy
Series	Mark VIe
Unique I/O Pack Redundance	Simplex
Revisions Applied (Total)	One Rev
V dc Value	24 V dc
Terminal Board	STCI
I/O Pack	PDIA I/O Pack

About the IS230SNCIH2A

The IS230SNCIH2A was manufactured by GE Energy for the Mark VIe Series. The IS230SNCIH2A is a Contact Input Module that is made up of an IS200STCI terminal board and a PDIA I/O pack.

IS230SNCIH2A Specifications

The IS230SNCIH2A accepts 24 contact inputs that are supplied with power from an external source. The IS230SNCI modules have different nominal dc excitation ratings. These are:

24 V dc
48 V dc
125 V dc

The IS230SNCIH2A has a nominal excitation rating of 24 V dc. The contact inputs are also designed with noise suppression to avoid surge and high frequency noises.

The IS230SNCIH2A is designed with 52 terminals. The PDIA I/O pack plugs into the D-type connector on the terminal board and communicates with controllers through Ethernet.

Frequently Asked Questions about IS230SNCIH2A

Does the IS230SNCIH2A have a fixed or pluggable terminal strip?

The IS230SNCIH2A has a pluggable terminal strip.

Can the IS230SNCIH2A be configured?

No, the IS230SNCIH2A is not configurable because there are no jumpers on the terminal board.

Are there diagnostics for the IS230SNCIH2A?

Yes, the IS230SNCIH2A has diagnostics through the I/O pack. The PDIA pack can alert users if there are faults on the pack and on the terminal board.

Reviews For IS230SNCIH2A

Internal Review

(4.0)

The IS230SNCIH2A does not allow for configurations, making this a four star part. This module does have a number of terminals, which allows for external connections to be made. The IS230SNCIH2A also has filters to reduce noise and surges near the inputs. - AX Control Lead Technician
