The IS230SNAIH2A is an Analog I/O Module that was manufactured by GE Energy for use in the Mark VIe Series

AVAILABILITY:

IN STOCK
SHIPS TODAY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230SNAIH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230SNAIH2A
SKU: GBTC-58790

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230SNAIH2A Technical Specifications

Part Number	IS230SNAIH2A
Product Type	Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
Input/Output Pack Redundancy	Simplex
I/O Pack	PAIC I/O Pack
Respective Terminal Board	IS200STAI
Mounting Strategy	DIN-Rail

About the IS230SNAIH2A

The IS230SNAIH2A is an Analog I/O Module that was manufactured by GE Energy. This module was designed for the Mark VIe Series. The module is comprised of an IS200STAI board and a PAIC I/O pack.

IS230SNAIH2A Specifications

The IS230SNAIH2A accepts 10 analog inputs and 2 analog outputs. The module can accommodate a four different types of transmitters. The inputs and outputs can have different voltage and current rating. These are:

+/- 5V, +/- 10V analog inputs
0-20 mA current analog outputs
0-200 mA current analog output

The PAIC I/O pack connects to the IS200STAI board via the D-type connector. The pack also communicates with the controller over Ethernet.

The IS230SNAIH2A has a total of 48 terminals that are Euro-block terminal block style.

Frequently Asked Questions about IS230SNAIH2A

What is the current rating of the analog outputs on the IS230SNAIH2A?

The analog outputs have a current rating of 0-20 mA.

Is the IS230SNAIH2A only available for simplex applications?

Yes, the IS230SNAIH2A only has one cable connection, making this module only available for simplex applications.

Reviews For IS230SNAIH2A

Internal Review

(5.0)

The IS230SNAIH2A can be configured using jumpers on the IS200STAI board. One configuration that can be made is an analog output being configured to 0-200 mA. This allows users with a higher current rating for one of the module's analog outputs. - AX Control Lead Technician
