IS230SHRAH2A

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The IS230SHRAH2A is a HART Enabled Analog I/O Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230SHRAH2A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230SHRAH2A
SKU: GBTC-58875

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230SHRAH2A Technical Specifications

Part Number	IS230SHRAH2A
Product Type	Hart Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
I/O Product Redundancy	Simplex GE Redundancy
I/O Pack Attached	PHRA
HART Status	HART Enabled
Mounting Structure	DIN Rail + Bracket
Power Distribution	DC Distribution

About the IS230SHRAH2A

The IS230SHRAH2A is a HART Enabled Analog Input/Output Module that was manufactured by GE Energy. This module was designed for use in the Mark VIe Series. The IS230SHRAH2A is made up of the IS200SHRAH terminal board and the IS220PHRA I/O pack. The I/O pack plugs into the D-type connector JA1 and can communicate with the controller over Ethernet.

IS230SHRAH2A Specifications

The SHRA terminal board accepts 10 analog inputs and 2 analog outputs. The analog inputs accommodate the following types of transmitters:

2-wire
3-wire
4-wire
externally powered transmitters

The analog outputs have a current rating of 4-20 mA.

The IS230SHRAH2A allows HART messages to be passed between the PHRA I/O pack and a HART enabled field device. The IS230SHRAH2A is compatible with all versions of the PHRA pack.

Frequently Asked Questions about IS230SHRAH2A

Can the IS230SHRAH2A be used for TMR applications?

No, there is only one cable connection on the IS230SHRAH2A, which means this module can only be used for simplex applications.

Does the IS230SHRAH2A have any diagnostic tests?

Yes, there are several diagnostic tests for the IS230SHRAH2A. One includes the I/O pack creating a diagnostic alarm when either of the two outputs is unhealthy.

Reviews For IS230SHRAH2A

Internal Review

(4.0)

The IS230SHRAH2A is only available in a simplex version, making this a four star part. There are other accommodations that the module can make, including accepting a variety of transmitter types on the analog inputs. 24 V dc power is available for the transmitters on the terminal board. - AX Control Lead Technician
