IS230SAIIH4A

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The IS230SAIIH4A is a Simplex Analog Input Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230SAIIH4A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230SAIIH4A
SKU: GBTC-58796

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230SAIIH4A Technical Specifications

Part Number	IS230SAIIH4A
Product Type	Isolated Analog I/O Module
Manufacturer	GE Energy
Series	Mark VIe
IS230SAIIH4A Pack Redundancy	Simplex I/O
I/O Pack Impacted	PAIC
I/O Signals	Isolated Analog Signals
Mark Series Product Grouping	Group Four

About the IS230SAIIH4A

The IS230SAIIH4A is a Simplex Analog Input Module that was manufactured by GE Energy. The IS230SAIIH4A was manufactured for the Mark VIe Series. The IS230SAIIH4A is made up of an IS200SAII terminal board and a PAIC I/O pack.

IS230SAIIH4A Specifications

The IS230SAIIH4A has 10 analog inputs and 2 analog outputs that are located on the terminal board of the module. The terminal board also connects to the PAIC I/O pack using the D-type connector. The PAIC is used to communicate with the controller over Ethernet.

The analog inputs have two specifications that are important to know. These are:

Each analog input has point isolation when configured for externally powered devices
Each analog input has an isolator in the circuit with a rating of 1500 V rms

There is an onboard ID chip that identifies the SAII board to the PAIC for system diagnostic purposes.

Frequently Asked Questions about IS230SAIIH4A

Is the IS230SAIIH4A compatible with the YAIC pack?

No, the IS230SAIIH4A is not compatible with the YAIC pack. This is because the YAIC pack is from the Mark VIeS Series.

Can the analog inputs on the IS230SAIIH4A be used with 2 wire transmitters?

Yes, the analog inputs can be used with 2 wire transmitters, along with 3 and 4 wire transmitters.

Reviews For IS230SAIIH4A

Internal Review

(5.0)

The IS230SAIIH4A has a number of analog inputs, which allow for a variety of connections to be made. The analog inputs can accommodate externally powered transmitters, as well as several wired transmitter types. The module also has terminal blocks that are Euro-block type. - AX Control Lead Technician

Repair Services For IS230SAIIH4A

Type	Lead Time	Price	Action
Repair Service	1-2 weeks	Ask	Get Quote

Our highly skilled technicians can repair your IS230SAIIH4A. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:

48-72hr Rush Repair
Detailed Repair Reports
AX Control Certificate of Warranty

AX Control Warranty Info

All products we sell are backed by our unparalleled warranty. A warranty certificate will be provided with your order upon request.

All PLCs, HMIs, and Turbine Control Boards:	3 Years
All AC/DC and Servo Drives:	2 Years
All Motors:	1 Year
