How many power supply inputs does the IS230JPDMG1B have?

The IS230JPDMG1B has three power supply inputs on JT, JR, and JS.

Does the IS230JPDMG1B have fuse protection?

Yes, the IS230JPDMG1B provides fuse protection for all outputs.

DS200AAHA1	GE Turbine Control	Mark V

DS200AAHA1	GE Turbine Control	Mark V

Home GE Boards & Turbine Control Mark VIe & Mark VIeS Control Systems IS230JPDMG1B

❮

❯

About | Product Specifications | FAQs

IS230JPDMG1B

4.50 (2)
Click a star to rate this product

4.50 (2)
Click a star to rate this product

The IS230JPDMG1B is a Power Distribution Module manufactured by GE Energy for the Mark VIe Series

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230JPDMG1B to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230JPDMG1B
SKU: GBTC-58880

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230JPDMG1B Technical Specifications

Part Number	IS230JPDMG1B
Product Type	Power Distribution Module
Manufacturer	GE Energy
Product Series	Mark VIe
Revision Table	Primary B-Rated Functional
I/O Module Redundancy	Simplex Redundancy
Power Supplies Accepted	TMR DC Power Supplies
Warranty Protection	Guaranteed
Abbreviation	JPDM

About the IS230JPDMG1B

The IS230JPDMG1B is a Power Distribution Module from the Mark VIe Series. This module was manufactured by GE Energy. The IS230JPDMG1B is comprised of an IS200JPDM board and a PPDA I/O pack.

The IS200JPDM board is designed to receive 28 V dc input power from external ac/dc or dc/dc converters. The board also distributes power to the control system. The PPDA I/O pack integrates the IS230JPDMG1B into the PDM system feedback.

The IS230JPDMG1B is compatible with feedback signal P1/P2 connectors from several other boards. These boards are:

JPDB boards
JPDF boards
JPDE boards

The JPDM board connects to the PPDA I/O pack using the DC-62 connector.

Reviews For IS230JPDMG1B

Internal Review

(5.0)

The IS230JPDMG1B is designed with a 28 V power output for the PPDA pack that ensures power system feedback is maintained even in the event of a channel power failure. This is an important feature that keeps the module working even during a failure. - AX Control Lead Technician
