The IS230JPDMG1A is a Power Distribution Module from the Mark VIe Series manufactured by GE Energy

AVAILABILITY:

CALL FOR AVAILABILITY

Contact: 1-919-372-8413 (Intl.), 1-800-991-7026 (US), sales@axcontrol.com

3 Year Warranty: Learn More About Our Warranty

Sell Surplus: Have a IS230JPDMG1A to sell? Sell Now

Exchange Credit: Learn more about our exchange credit program

Part Number: IS230JPDMG1A
SKU: GBTC-58879

Manufacturer: GE Boards & Turbine Control
Series: Mark VIe & Mark VIeS Control Systems

Description
Repairs
Warranty
Manuals

IS230JPDMG1A Technical Specifications

Part Number	IS230JPDMG1A
Product Type	Power Distribution Module
Manufacturer	GE Energy
Series	Mark VIe
Redundance of I/O Packs	Simplex Redundant
Primary Rev	Common A-Rated Functional Rev
Product Grouping	Group One
Power Supplies Supported	TMR DC Power Supplies

About the IS230JPDMG1A

Hardware Tips and Specifications

The IS230JPDMG1A is a Power Distribution module from GE Energy's Mark VIe Series. The IS230JPDMG1A is made up of an IS200JPDM board and a PPDA I/O pack, along with a metal bracket for mounting.

The IS230JPDMG1A receives 28 V dc input power through the JPDM board, which is supplied with this power by an external source. This source is either an ac/dc converter or a dc/dc converter.

There are several specifications to know about the IS230JPDMG1A module. Some of these specifications are:

Simplex standard I/O pack redundancy
PPDA I/O pack compatible
DIN rail mounting version
DC power distribution
TMR DC power supply support

Reviews For IS230JPDMG1A

Internal Review

(5.0)

The IS230JPDMG1A is compatible with several feedback signal connectors on different boards. The boards that the IS230JPDMG1A can work with are the JPDB, JPDF, and JPDE. The feedback signal connectors on these specified boards are P1 and P2. - AX Control Lead Technician
