The IS220PPDAH1BE PDM Diagonal BPPC Based I/O Pack was manufactured by GE Energy for the Mark VIe Series. This I/O Pack comes with two significant revisions, as indicated by the trailing "BE" digits in the IS220PPDAH1BE part number.



Sell Surplus: Have a IS220PPDAH1BE to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: IS220PPDAH1BE
  • Manufacturer: GE Boards & Turbine Control
  • Series: Mark VIe & Mark VIeS Control Systems

IS220PPDAH1BE Technical Specifications

Manufacturer GE Energy
Series Mark VIe
Part Number IS220PPDAH1BE
Functional Acronym PPDA
Functional Description PDM Diagonal BPPC Based I/O Pack
PCB Coating Conformal Coating
Functional Revision 1 B
Functional Revision 2 E

Product Description

This IS220PPDAH1BE printed circuit board was originally manufactured by General Electric, for use in their Mark VIe Series of turbine control systems and turbine control system products. This printed circuit board can be tracked down to more specific origins in the GE Energy factory plant located in Salem, Virginia. GE Energy is the General Electric Subsidiary company responsible for the manufacture of all of General Electirc's Mark VIe Turbine Control System Series. This IS220PPDAH1BE model PCB is actually a two times-revised version of a different GE Energy parent printed circuit board; the IS220PPDAH1 model. This printed circuit board or PCB for short can additionally be more carefully explained by its functional description as a PDM Diagonal BPPC Based I/O Pack.

Hardware Tips and Specifications

Before attempting to decipher any of the available hardware components made useful to this IS220PPDAH1BE PDM Diagonal BPPC Based I/O Pack, it remains important to understand the actual functionality of the product for true contextualization. In its simplest form, PPDA I/O pack is responsible for the production of system feedback signals for ground fault detection, power bus voltages, branch circuit statuses, and bulk power supply health in the greater Mark VIe Series automated drive assembly. Many core components in the Mark VIe Series' PDM connect to the IS220PPDAH1BE model printed circuit board through the use of ribbon cable connectors, in order to access these crucial diagnostic applications.

Now that some of the intended purpose of this IS220PPDAH1BE product has been revealed, it is possible to understand its various hardware component placements on a different level. For instance, this diagnostic process-geared circuit board makes use of a unique set of LED visual indicators, all aimed at displaying fault or trip conditions. Perhaps it is this board's connectivity to a range of over five compatible Mark VIe option boards that contributes to its status as a special assembly model, as is specified by its specialized IS220 series alignment tag. Atypical of many similar Mark VIe Series I/O pack components; this IS220PPDAH1BE board makes use of not one, not three, but two significant product revisions; both revisions aimed at elevating the functionality or increasing the overall efficiency of this IS220PPDAH1BE PDM Diagonal DPPC Based I/O Pack. In another unique turn, this IS220PPDAH1BE PCB makes use of the seldom-seen E-rated functional revision 2 in its assembly.

Some additional supplemental information concerning this IS220PPDAH1BE printed circuit board can be obtained from a simple analysis of the IS220PPDAH1BE product number itself. This number outlines information such as this product's special assembly version, its PPDA functional acronym, its two functional revisions, and its conformal style of PCB protective coating, which should be chemically applied to every component affixed to the base board of this GE Energy Mark VIe Series model PCB.

Frequently Asked Questions about IS220PPDAH1BE

Is this IS220PPDAH1BE PDM Diagonal BPPC Based I/O Pack compatible with any special IS2020-assembly boards?

Yes. This IS220PPDAH1BE PDM Diagonal BPPC Based I/O Pack is compatible with a number of special-assembly modules, including the IS2020JPDB and the IS2020JPDF.

Are this IS220PPDAH1BE product's two functional revisions backwards-compatible?

Yes. This IS220PPDAH1BE board, while featuring a unique E-rated functional revision, is considered to possess backwards compatibility in its revisions.

Is this IS220PPDAH1BE printed circuit board protected by any sort of warranty upon purchase?

Yes. As with the majority of our stock of new or refurbished General Electric printed circuit boards; this IS220PPDAH1BE model PCB ships protected by our guaranteed three-year warranty upon original purchase.

Reviews For IS220PPDAH1BE

Internal Review

This IS220PPDAH1BE PDM Diagonal BPPC Based I/O Pack is a specialized and crucial GE Energy Mark VIe Series product offering that lives up to its lengthy title. This GE printed circuit board is a well-supported PCB; given its inclusion of the highly-rated IS220 special assembly version, which is most likely encouraged by its inclusion of several compatible option boards for correct functioning. This IS220PPDAH1BE PCB also makes use of the specialized E-rated secondary functional revision in its assembly, which in this case is backwards-compatible. This IS220PPDAH1BE model board is available for both repair and replacement here at AX Control, with a standard one to two week lead time on repairs. - AX Control Lead Technician
