IS200TBCIH2BBC

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.88 (16) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.88 (16)
  • Click a star to rate this product


The IS200TBCIH2BBC Contact Input Terminal Board

New Surplus Factory Package
SKU: 22MVMVCS1
3 Year Warranty:
New Surplus AX Control Package
SKU: 22MVMVCS2
3 Year Warranty:
Reconditioned
SKU: 22MVMVCS3
3 Year Warranty:
Repair
$1115
SKU: 22MVMVCS4
3 Year Warranty:

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the IS200TBCIH2BBC

This IS200TBCIH2BBC printed circuit board is a product that was originally mass-produced by GE Energy, the subsidiary alternative energy manufacturer of industrial giant General Electric. This IS200TBCIH2BBC printed circuit board or PCB was manufactured specifically for GE's Mark VIe Wind Turbine Control System Series, which likely explains its manufacture by the specialized GE Energy company.

This IS200TBCIH2BBC Contact Input Terminal Board exists as a modified version of the original IS200TBCIH2 parent circuit board; possessing three significant product revisions graded at B, B and C respectively. This PCB can be more explicitly defined through its instructional manual-stated functional description as a Contact Input Terminal Board.


IS200TBCIH2BBC Contact Input Terminal Board Hardware and Specifications

The IS200TBCIH2BBC Contact Input Terminal board offers a wide array of unique hardware components and specifications that all contribute to its intended terminal board functionality. This PCB is a wide-reaching terminal board, accepting 24 total dry contact inputs in its assembly. In addition to this, the IS200TBCIH2BBC board accepts wired DC power for contact excitation purposes. These two applications are the sole focus of this TBCI-abbreviated board's functionality, which should contextualize some of its specific hardware choices well.

One primary hardware component inclusion in the assembly of this TBCI Contact Input Terminal Board is obvious in its series of DC-37 pin connectors with latching fasteners that have been included for connectivity purposes. Other relevant connector types included in this board's assembly include:

  • connections made from this board's:
    • JS1 port
    • JR1 nomenclature-labeled port

 Another important piece of hardware included in this TBCI board's assembly is its series of high-frequency noise suppression filters. This printed circuit board does not make an attempt to incorporate any sort of customizable hardware, including manually moveable hardware jumpers into its assembly, although it is a revised PCB featuring two functionality-aimed functional revisions and a singular board artwork configuration-altering revision.

It is important to note that this device's three-fold revision history alters the hardware configuration and performance specifications from its original IS200TBCIH2 GE Energy parent design status; which the material on this page has been describing thus far due to its availability of instructional manual materials.


IS200TBCIH2BBC Technical Specifications

Manufacturer GE Energy
Series Mark VIe
Part Number IS200TBCIH2BBC
Functional Acronym TBCI
Functional Description Contact Input Terminal Board
PCB Coating Conformal Coating
Functional Revision 1 B
Functional Revision 2 B
Artwork Revision C

Frequently Asked Questions about IS200TBCIH2BBC

Why doesn't this board's functional description as a Contact Input Terminal Board match up directly with the TBCI functional acronym?

While GE-specified functional acronyms are meant to symbolize their specific products's different functionalities; they only rarely match up exactly. In this case, it appears that this product's Contact Input Terminal Board status is switched to a Terminal Board with Contact Inputs in the reversed TBCI functional acronym.

Are this IS200TBCIH2BBC printed circuit boards' two functional revisions backwards-compatible?

Yes. Given that this TBCI-abbreviated product's two functional revisions are both rated at "B" grades, it should come as no surprise that they are considered backwards-compatible.

Which Mark VIe Series group does this IS200TBCIH2BBC model belong to?

As evidenced by this product's inclusion of the H2 series grouping tag in its individualized product number; this IS200TBCIH2BBC PCB has a group 2 Mark VIe Series grouping.
