About the DS200ACLEH1
The DS200ACLEH1 functions as a Hub LAN Driver Card. This is an application control layer board that is sometimes used with an added PC/104 ISBus extension board to create a control layer module that can perform multiple duties over the MKV communication networks. The DS200ACLEH1 can communicate with various parts of the MKV system, including the Control System Toolbox (via TCP/IP) and the CIMPLICITY graphics software (via Ethernet.) The DS200ACLEH1 is populated by various components on its rectangular surface, including a read-only chip with the board’s:
- serial number
- major and minor revision record
- board catalog number
The board has an onboard timer (programmable) that will produce a periodic time signal to the DSPX board through a LAN signal carried via the P1 connector. Other DS200ACLEH1 components include a CPU chip, a header connector to connect to the optional board component, various vertical pin ribbon connectors (male and female) transistors, resistors, diodes, and capacitors. For a more complete picture of the DS200ACLEH1 board, please refer to data sheets, user guides or manuals originally published by General Electric.
DS200ACLEH1 Product Number Components
The DS200ACLEH1 functional product number begins with the DS200 series tag delegating this DS200ACLEH1 device's normal Mark V Series assembly version as well as its domestic original manufacture location. This dual-functional tag is followed in the DS200ACLEH1 functional product number by:
- the ACLE functional product abbreviation
- the H1 series grouping tag
- dual naming responsibilities:
- conformal coating style
- group one Mark V Series product grouping
