F1-130DR-D Image 1
F1-130DR-D Image 2

F1-130DR-D

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.75 (4)
  • Click a star to rate this product
10 DC Input, 8 Relay Output DL105 Module 10-30 VDC

AVAILABILITY:

CALL FOR AVAILABILITY

Sell Surplus: Have a F1-130DR-D to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: F1-130DR-D
  • SKU: F1130DRDAD
  • Manufacturer: Automation Direct
  • Series: DirectLogic 105

Product Description

This product is a 10 DC Input, 8 Relay Output DL105 Module that was made by Automation Direct. This module is a product of Koyo, PLC Direct, and Facts engineering working together. This version of the module has a 10-30 VDC power supply instead of a VAC powered output. To protect the module from noise pollution, the module has a protective NEMA casing. The diagnostics of the module allow the users to debug and identify problems. The drive has the dimensions 5.12 x 3.16 x 3.63. The ambient temperature that best works for the module between -20 and 70 degrees Celsius.

The 10 DC Input, 8 DC Output DL105 Module has 3 isolated input commons and 3 internally connected output commons. The voltage range of the input runs between 94-240 VAC. The output voltage range volleys between 100-240 VDC. The module has a 12 amp inrush current with a maximum running current of 1.7 amps.

The 10 DC Input, 8 DC Output DL105 Module has a ladder memory structure that allows for the manipulation of data. The module has a 2.4K retentive memory space for storing data. The system runs on the DirectSOFT programming software built into the system. The Device comes with RS-232-C port that transfers module data at 9600 baud. The system also has forced I/O, timer/event drum sequencing, and RLL diagram-style programming.

The module is listed as F1-130DR-D and the D1-USER-M Manual assists the user in making the machine function properly. Call us now to get pricing quotes and information about our warranties.

Repair Services For F1-130DR-D

Type Lead Time Price Action
Repair Service 1-2 weeks $289

Our highly skilled technicians can repair your F1-130DR-D. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
