F1-130AR

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.27 (11) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.27 (11)
  • Click a star to rate this product


The F1-130AR is a PLC with 10 discrete input points and 8 discrete output points that was manufactured by Facts Engineering

New Surplus Factory Package
$1245
SKU: 4DI1
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus AX Control Package
SKU: 4DI2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
$855
SKU: 4DI3
3 Year Warranty:
Order Before 3PM EST
Rush Available
2 in Stock
Repair
$256
SKU: 4DI4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

  Shipping Weight: 8.0 lbs.

  Shipping Dimensions: 16" x 16" x 16"

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the F1-130AR

The F1-130AR is a Programmable Logic Controller that was manufactured by Facts Engineering. This commissioned product was made, in collaboration, by Facts Engineering, Koyo, and PLC Direct. This module can work with many workspaces because the system is mountable onto other structures. The ambient temperature of the device is between -20 and 70 degrees Celsius. To keep the module safe from noise pollution, the NEMA casing of the module was built with a noise immunity.

This DL105 Module has a ladder structure the organizes the data individually of each bit. The retentive memory of the system reaches a limit of 2,400. This device uses DirectSOFT programming software as the main programmer of the system. The system all comes with a forced I/O, a timer/event drum sequencer, and an RLL diagram-style programming.

The F1-130AR has a range of features that are helpful for users. Some of these include:

  • Removable connectors
  • +24 VDC Auxiliary power supply
  • RS-232C communication port

The 10 AC Input, 8 Relay Output DL105 Module comes with 3 isolated input commons and 4 isolated output commons that transfers data between the module and other devices. The input voltage range of the module runs between 94 and 240 VAC. The module's output voltage range runs between 100 and 240 VDC. The current reaches its highest point at 1.7 amps.

The D1-USER-M Manual is the literature that assists the user in making the machine function properly.

F1-130AR Manuals, White Papers, Data Sheets, and Troubleshooting

F1-130AR Technical Specifications

Part Number F1-130AR
Module Type Programmable Logic Controller
Series DirectLogic 105
Manufacturer Facts Engineering
Country of Manufacturer United States
Software DirectSOFT
Voltage Range (VAC) 94-240 VAC
Voltage Range (VDC) 100-240 VDC
Total Memory 2.4k Words
Output Circuitry Relay

Frequently Asked Questions about F1-130AR

Is the F1-130AR expandable?

No, the Direct Logic 105 series does not have expandable features for its PLCs.

Does the F1-130AR have LED indicators?

Yes, the F1-130AR has LED indicators. These include RUN, PWR, and CPU.

Reviews For F1-130AR

Internal Review
(5.0)

There are three main approaches to solving the application program for the F1-130AR. There are Standard RLL programming and Stage Programming, in addition to Timer/Event Drum Sequencer. The F1-130AR can be replaced by other modules from other series, although there will likely be differences between the two modules. This allows users to have more flexibility if their unit needs replacing. - AX Control Lead Technician
