Home Automation Direct DirectLogic 105 F1-130AA
In Stock
F1-130AA Image One
3 year warranty
visa card logo american express logo master card logo bbb logo duns seal

About | Product Specifications | FAQs

International

Phone

1-919-372-8413

Domestic (US)

1-800-991-7026

Email

F1-130AA

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 5.00 (4) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 5.00 (4)
  • Click a star to rate this product


The F1-130AA is a Programmable Logic Controller with 10 Discrete Input points and 8 Discrete Output points that was manufactured by Facts Engineering

New Surplus Factory Package
SKU: 2DI1
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

New Surplus AX Control Package
SKU: 2DI2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
$460
SKU: 2DI3
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Repair
$290
SKU: 2DI4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

  Shipping Weight: 5.0 lbs.

  Shipping Dimensions: 10" x 10" x 10"

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the F1-130AA

Automation Direct commissioned the F1-130AA Module as part of the D105 family. Koyo, PLC Direct, and Facts Engineering collaborated to fill the commission for the product. This module has 10 Input points and 8 output points.

There are some specifications to know about the module. Some of these are:

  • Dimensions of 5.12 x 3.16 x 3.63
  • Temperature range between 0 and 50 degrees Celsius
  • Protective NEMA casing

The diagnostics of the module allow the users to debug and identify problems within the module.

The DL105 Module has a ladder memory structure that allows for the individual manipulation of data. The device has a 2.4k retentive memory for data processing. The DirectSOFT programming software controls the way the system communicates within itself. The device's RS-232-C port transfers data at 9600 baud. The system has other features like forced I/O, timer/event drum sequencing, and RLL diagram-style programming.

The F1-130AA has 3 isolated input commons and 4 isolated output commons. The voltage ranges of the input runs are between 94-240 VAC. The output voltage range volleys between 100-240 VDC. The module has a 12 amp inrush current with a maximum running current of 1.7 amps.

The module is listed as F1-130AA and the D1-USER-M Manual is the literature that assists the user in making the machine function properly.

F1-130AA Manuals, White Papers, Data Sheets, and Troubleshooting

F1-130AA Technical Specifications

Part Number F1-130AA
Manufacturer Facts Engineering
Series DirectLogic 105
Module Type Programmable Logic Controller
Number of Input Points 10 Points
Number of Output Points 8 Points
Voltage Range (VDC) 100-240 VDC
Voltage Range (VAC) 94-240 VAC
Communication Port RS-232 port
Country of Manufacturer United States

Frequently Asked Questions about F1-130AA

Does the F1-130AA contain the CPU already?

Yes, the F1-130AA contains the CPU, power supply, and I/O all in one module.

How can the F1-130AA be programmed?

The F1-130AA can be programmed with a software programming package or with a handheld programmer.

Reviews For F1-130AA

Internal Review
(4.0)

The F1-130AA is a Micro PLC that has a variety of features all in one unit. The module includes removable connectors and an RS-232C port for communications. This module also includes a +24V auxiliary output, which is a feature on the AC units of the DL105 series. The F1-130AA does not have pulse outputs or high speed inputs, which is one negative for this unit. - AX Control Lead Technician

F1-130AA Technical Specifications

Part Number F1-130AA
Manufacturer Facts Engineering
Series DirectLogic 105
Module Type Programmable Logic Controller
Number of Input Points 10 Points
Number of Output Points 8 Points
Voltage Range (VDC) 100-240 VDC
Voltage Range (VAC) 94-240 VAC
Communication Port RS-232 port
Country of Manufacturer United States

About the F1-130AA

Automation Direct commissioned the F1-130AA Module as part of the D105 family. Koyo, PLC Direct, and Facts Engineering collaborated to fill the commission for the product. This module has 10 Input points and 8 output points.

There are some specifications to know about the module. Some of these are:

  • Dimensions of 5.12 x 3.16 x 3.63
  • Temperature range between 0 and 50 degrees Celsius
  • Protective NEMA casing

The diagnostics of the module allow the users to debug and identify problems within the module.

The DL105 Module has a ladder memory structure that allows for the individual manipulation of data. The device has a 2.4k retentive memory for data processing. The DirectSOFT programming software controls the way the system communicates within itself. The device's RS-232-C port transfers data at 9600 baud. The system has other features like forced I/O, timer/event drum sequencing, and RLL diagram-style programming.

The F1-130AA has 3 isolated input commons and 4 isolated output commons. The voltage ranges of the input runs are between 94-240 VAC. The output voltage range volleys between 100-240 VDC. The module has a 12 amp inrush current with a maximum running current of 1.7 amps.

The module is listed as F1-130AA and the D1-USER-M Manual is the literature that assists the user in making the machine function properly.

F1-130AA Manuals, White Papers, Data Sheets, and Troubleshooting

Frequently Asked Questions about F1-130AA

Does the F1-130AA contain the CPU already?

Yes, the F1-130AA contains the CPU, power supply, and I/O all in one module.

How can the F1-130AA be programmed?

The F1-130AA can be programmed with a software programming package or with a handheld programmer.

Reviews For F1-130AA

Internal Review
(4.0)

The F1-130AA is a Micro PLC that has a variety of features all in one unit. The module includes removable connectors and an RS-232C port for communications. This module also includes a +24V auxiliary output, which is a feature on the AC units of the DL105 series. The F1-130AA does not have pulse outputs or high speed inputs, which is one negative for this unit. - AX Control Lead Technician
