H0-ECOM

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.80 (5) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.80 (5)
  • Click a star to rate this product


The H0-ECOM is an Ethernet Communications Module that was manufactured by Host Automation

New Surplus Factory Package
$840
SKU: 25DI1
3 Year Warranty:
Order Before 3PM EST
Rush Available
3 in Stock
New Surplus AX Control Package
$440
SKU: 25DI2
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Reconditioned
$356
SKU: 25DI3
3 Year Warranty:
Order Before 3PM EST
Rush Available
3 in Stock
Repair
$292
SKU: 25DI4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

  Shipping Weight: 2.0 lbs.

  Shipping Dimensions: 8" x 8" x 8"

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the H0-ECOM

The H0-ECOM Ethernet Communications module is designed for use on a 10/100 BaseT (twisted pair, copper wire) Ethernet network. The H0-ECOM Ethernet Communications module connects to the network using standard RJ45 modular connectors.

The H0-ECOM Ethernet Communications module can be used to share data between two or more DirectLOGIC PLCs or between DirectLOGIC PLCs and a laptop, desktop, or other device. The H0-ECOM Ethernet Communications module provides a low-cost, high-speed Ethernet link for DL05 series, DL06 series, and DL405 series PLC devices.

The front of the H0-ECOM Ethernet Communications module provides status indicators.

  • OK The H0-ECOM is powered up and functional.
  • LINK When green, the module is properly connected to the network.
  • ACT Red or flashing red indicates active network data.
  • ERR When red, or flashing red, a fatal error has occurred.

The H0-ECOM can use a laptop, desktop, or other device with a 10/100BaseT network adapter card installed and NetEdit3 software to configure the module over the network. You can also use the NetEdit3 software for troubleshooting some communication problems.

The NetEdit3 software utility can be used to set network identifiers (Module ID or IP Address) and upgrade the firmware in the H0-ECOM module.

Users can also assign a module ID using the DIP switches on the module. Users can make sure of the DIP switches if they want the ability to install or change modules without using a laptop, desktop, or other device to set the Module ID.

H0-ECOM Manuals, White Papers, Data Sheets, and Troubleshooting

H0-ECOM Technical Specifications

Part Number H0-ECOM
Manufacturer Host Automation
Series DirectLOGIC 06
Option Card Type Ethernet Comms Module
Communication Port 10BaseT Ethernet
Ethernet Port RJ45
Power Consumption 300 mA @ 5 VDC
Software DirectSOFT
Weight 0.1 lbs
Status Indicators OK; Link; Act; Error

Frequently Asked Questions about H0-ECOM

What are some offerings of the H0-ECOM?

The H0-ECOM offers a high speed peer-to-peer networking for PLCs. The module also offers Modbus TCP Client/Server protocol.

Which option slot can the H0-ECOM be used in?

The H0-ECOM can be used in any option slot of the DL05 or DL06 series.

Reviews For H0-ECOM

Internal Review
(4.0)

The H0-ECOM is an Ethernet module that offers a range of protocols for users to make use of. The module is a high performance option for users and offers fast updates using the DirectSOFT programming software. The H0-ECOM can be used in any of the option slots on the PLC. The module can also be used with multiple series from Automation Direct. The H0-ECOM is a precursor to the H0-ECOM100, which offers faster networking. - AX Control Lead Technician
