D0-06DD1

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.63 (8) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.63 (8)
  • Click a star to rate this product


The D0-06DD1 has 20 Discrete Inputs and 16 Discrete Outputs and is a 120 to 240 VAC PLC manufactured by Automation Direct

New Surplus Factory Package
SKU: 4DI1
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

New Surplus AX Control Package
SKU: 4DI2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
$575
SKU: 4DI3
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Repair
$283
SKU: 4DI4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

  Shipping Weight: 3.0 lbs.

  Shipping Dimensions: 18" x 12" x 12"

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the D0-06DD1

The D0-06DD1 is a Programmable Logic Controller from Automation Direct's DirectLOGIC 06 series. This unit can be used to control and monitor industrial devices. The D0-06DD1 has flexible features, including expandable I/O points and multiple communications options.

There are several characteristics for the DL06 Micro PLC Model D0-06DD1 to keep in mind:

  • From 100 to 240 VAC/50-60 Hz and 40 VA or lower is the power requirement from an external source.

  • Input voltage: Values are 10.8 at the lowest and 26.4 VDC at the high end (standard/high-speed).

  • From 12 to 24 VDC (standard and high-speed inputs) is the voltage rating for the device while operating. Five banks are supported. While 4 inputs in each bank is supported. One common terminal is in each bank (sinking or sourcing) inputs.

  • The output voltage range is 5-30 VDC and the operating voltage range is 6-27 VDC for standard and pulse outputs. The 16 sinking DC outputs share a common terminal.

  • The DL06 Micro PLC D0-06DD1 boasts V-memory. The memory is in 16-bit registers.

  • There is an​ ​RS–232C​ ​communication​ ​port​ ​and​ ​one​ ​RS232C/RS422/RS485​ ​port. Port 1 has a ​6-pin​ ​modular​ ​connector.​ ​Port​ ​2​ ​is​ ​a​ ​15-pin​ ​HD-sub connector.

The D0-06DD1 can be used with a laptop to program the device. Users can use Port 1 or Port 2 to connect to the laptop.

D0-06DD1 Manuals, White Papers, Data Sheets, and Troubleshooting

D0-06DD1 Technical Specifications

Manufacturer Automation Direct
Product Type PLC
Series DirectLogic 06
Part Number D0-06DD1
Weight 1.8 lbs
Software DirectSOFT
Expansion Modules Allowed 4
Discrete Output Type Sinking
Discrete Input Type Sinking or sourcing
Manual Number D0-06USER-M

Frequently Asked Questions about D0-06DD1

What does it mean if the CPU indicator is blinking on the D0-06DD1?

The CPU indicator blinking means that the battery is less than 2.5 VDC.

Can the D0-06DD1 be connected to the handheld programming device for the DL 06 series?

Yes, the D0-06DD1 can connect to the Handheld Programming device. This can be useful for users who need a compact and portable device. The device can be connected using Port 1.

Reviews For D0-06DD1

Internal Review
(5.0)

The DirectLogic 06 DL06 Micro PLC from Automation Direct are expandable micro PLCs that give you multiple options for managing your industrial processes. The same panel layout can remain for applications with 36 to 100 I/O, and the unit offers 20 fixed inputs and 16 outputs along with four expansion slots. The D0-DCM supports Ethernet, DeviceNet Slave, MODBUS RTU master/slave, Profibus slave, and ASCII in/out. - AX Control Lead Technician
