About the D0-05DR-D
The DL05 Micro PLC Model D0-05DR-D has two RS–232C communication ports and 8 DC inputs and 6 relay contact outputs. The D0-05AD features operating modes that are accessed through a switch on the device or are available from a programming device or optional DirectSOFT 5 programming software. The modes enable programming functions.
Port 1 on the D0-05DR-D is a 6-pin modular connector that can be connected to a programming device, or other device containing optional programming software. Port 2 is a 6-pin modular connector and it offers RS-232 communications only. Inputs are organized into two banks of four. Each bank has an isolated common terminal, and may be wired as either sinking or sourcing inputs. The DL05 Micro PLC D0-05DR-D offers data storage in V-memory in 16-bit registers and advanced internal diagnostics.
D0-05DR-D PLC Ratings and Requirements
Some of this D0-05DR-D Programmable Logic Controller's most-relevant voltage ratings are its:
- external power requirement of 12-14 VDC, 20 W maximum
- input voltage range of 10.8-26.4 VDC
- operating voltage range of 12-24 VDC
- relay output voltage range of 5 -264 VAC (47 -63 Hz), 5 - 30 VDC
- operating voltage range of 6-240 VAC (47-63 Hz), 6-27 VDC
Outputs are organized into two banks of three relay contacts. Each bank has a common terminal. The ambient operating temperature is 32ºF-131ºF (0º to 55ºC) and the ambient humidity is 5 to 95% relative humidity (non-condensing).
