The CM5-T4W C-more CM5 Series Touch Panel by Automation Direct

New Sealed Factory Package
$815
SKU: 6CCSTP1
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus Factory Package
SKU: 6CCSTP2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

New Surplus AX Control Package
SKU: 6CCSTP3
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
SKU: 6CCSTP4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Repair
$395
SKU: 6CCSTP5
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the CM5-T4W

The CM5-T4W is an Automation Direct HMI from the C-more CM5 Series Touch Panels. The CM5-T4W has an analog resistive touch screen that is designed to respond to a single touch. This HMI has over 16 million colors that allow for enhanced graphics on screen with a display resolution of 480 x 272 WQVGA. The CM5-T4W also has a built-in project simulation mode that can be tested on a PC during development.

The CM5-T4W has a variety of different ports that allow for external connections. Two of these ports include serial ports. These are an RJ12 modular jack, which allows connections for RS-232C standards, and a DB-15 port, which allows connections for RS-232C, RS-422, and RS-485 standards. The other ports that the CM5-T4W have are:

  • SD Card Slot (1)
  • USB Port (2)
  • Ethernet Port (1)

There is a USB Type A port and a USB Type B port. The CM5-T4W also comes equipped with LED status indicators that allow users to see whether Ethernet has been linked or if there is any communications activity.

CM5-T4W Technical Specifications

Part Number CM5-T4W
Manufacturer Automation Direct
Series C-more CM5 Series Touch Panels
Screen size 4.3 inch
Operating Temperature 0 to 50 degrees Celsius
Project Memory 45 MB
Display Brightness 310 nits
Number of Serial Ports 2 Serial Ports
Weight 0.46 lbs
Enclosure Type NEMA 4/4X
Environment Type Pollution Degree II; no corrosive gases
Country of Origin Japan

Frequently Asked Questions about CM5-T4W

Can the CM5-T4W be used outdoors?

No, the CM5-T4W is designed for indoor use only.

How can the CM5-T4W be programmed?

Programming to the CM5-T4W can be done using the USB Type B port or through the Ethernet port.

Reviews For CM5-T4W

Internal Review
(4.0)

The CM5-T4W is the smallest HMI from the C-more CM5 Series, which also gives it the lowest resolution. The CM5-T4W is still a useful unit despite its smaller size. The CM5-T4W is extremely lightweight and compact, making it easier for users to install this touch panel. This HMI also still allows for a variety of different communications options. - AX Control Lead Technician
