The CM5-T12W HMI C-more CM5 Series Touch Panels by Automation Direct

New Sealed Factory Package
$1665
SKU: 3CCSTP1
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus Factory Package
SKU: 3CCSTP2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

New Surplus AX Control Package
SKU: 3CCSTP3
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
SKU: 3CCSTP4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Repair
$985
SKU: 3CCSTP5
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the CM5-T12W

The CM5-T12W has a 12.1 inch display and is from the C-more CM5 Series Touch Panels. This unit was manufactured by Automation Direct. The CM5-T12W is 3.44 pounds and has a color TFT Liquid Crystal Display. The CM5-T12W has cutout dimensions of 11.91" x 8.92".

The CM5-T12W can have up to 999 screens, which is in part due to the 90MB of project memory that the unit has. The CM5-T12W can also store alarms and messages through the retentive memory the unit has.

The CM5-T12W has a display with the following specifications:

  • Analog resistive touch screen
  • 1280 x 800 WXGA display resolution
  • LED backlight
  • 16.7 M color scale

The CM5-T12W should be used indoors only. The CM5-T12W can be used in a Pollution Degree II environment where there are no corrosive gases. The touch panel should be used in an environment with 5-95% relative humidity that is non-condensing. The HMI can also be used in environments up to 2000m high.

CM5-T12W Technical Specifications

Part Number CM5-T12W
Series C-more CM5 Series Touch Panels
Manufacturer Automation Direct
Display Size 12.1 inch
Operating Temperature 0 to 50 degrees Celsius
Storage Temperature -20 to 60 degrees Celsius
Weight 3.44 lbs
Number of Serial Ports 3 Serial Ports
Enclosure Type NEMA 4/4X
Display Brightness 280 nits
Backlight Average Lifetime 50,000 hours @ 25 degrees Celsius
Software CM5-PGMSW
Made in Japan

Frequently Asked Questions about CM5-T12W

How many USB ports does the CM5-T12W have?

The CM5-T12W has 4 USB ports. One is a Type B port, while the other 3 are Type A ports.

What is the nominal wattage that the CM5-T12W can accept?

The CM5-T12W can accept 35.0 W. The CM5-T12W also runs on 12-24 VDC from an external power source.

Reviews For CM5-T12W

Internal Review
(5.0)

The CM5-T12W can be used to receive and transfer data to and from external devices. This happens using the USB ports, Ethernet ports, and Serial ports. These serial ports are a 15-pin D-sub female port, an RJ-12 modular jack, and a 3-wire terminal block. The Ethernet ports support Ethernet 10/100 Base-T capabilities. The Ethernet connection can also be used for programming. - AX Control Lead Technician
