Miscellaneous Woodward Discreet Output Module 5462-758 has two different colors for the twenty-nine LED indicators, twenty-eight of these LEDs will light up orange while the remaining LED will light up red.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 5462-758 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5462-758
  • SKU: 5462758WO
  • Manufacturer: Woodward
  • Series: Power Supplies, Controllers, & Miscellaneous

5462-758

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.00 (2)
  • Click a star to rate this product
Miscellaneous Woodward Discreet Output Module 5462-758 has two different colors for the twenty-nine LED indicators, twenty-eight of these LEDs will light up orange while the remaining LED will light up red.

AVAILABILITY:

IN STOCK
SHIPS TODAY

3 Year Warranty: Learn More
Sell Surplus: Have a 5462-758 to sell? Sell Now
Exchange Credit: Learn more about our exchange credit program
  • Part Number: 5462-758
  • SKU: 5462758WO
  • Manufacturer: Woodward
  • Series: Power Supplies, Controllers, & Miscellaneous

5462-758 Technical Specifications

# LEDs 28 Orange, 1 Red
# of Pins in Input Slot 120
Dimensions (in) 8 7/8 W x 7 5/8 H x 1/2 D
Manufacturer Woodward - Fort Collins, Colorado
Weight Less than 2 lbs. before Packaging

Product Description

The Miscellaneous Discreet Output Module 5462-758 is a module that was manufactured by Woodward Incorporated out of Fort Collins Colorado. Due to no longer being in production this module has very limited documentation. This module has twenty-nine light-emitting diodes (LEDs). There are two different colors of these LEDs, twenty-eight of them are typically orange with the remaining LED lighting up red.

The dimension specifications of the 5462-758 module are as follows; a height of seven and five-eighths inches, a width of eight and seven-eighth inches, and a depth of half an inch. These dimensions indicate that the module will be approximately less than two pounds prior to it being packaged and shipped.

There is an input slot on this module, with a large range of pins, the number of pins on this input slot totals one hundred and twenty pins. There is a small fan on this module which can potentially be used to cool the module. On each corner of the module, there is a hole that is likely used to connect this module to the chosen chassis or base.

We offer international shipping and free domestic shipping. Contact our sales team today for a free quote by email at sales@axcontrol.com or by phone at 1-919-372-8413. All Woodward purchases come standard with our industry-leading satisfaction-guaranteed 3-year warranty!

  • 5462-758 B
  • 5462-758 C
  • 5462-758 D
Reviews For 5462-758
Internal Review

Due to a lack of public documentation on this board, it may be difficult for our tech/sales team to provide advanced assistance on this unit outside of our regular buying, selling, or repair. We apologize for any inconvenience this may cause. - AX Control Inc.

Repair Services For 5462-758

Type Lead Time Price Action
Repair Service 1-2 weeks $1289

Our highly skilled technicians can repair your 5462-758. All of our repairs come with a 3 Year AX Control Warranty. Please contact us for additional information about our repair process. To receive the repair pricing and lead time listed above please process your repair order via our website. The following repair options may be available upon request:
