About the 8440-1947
The 8440-1947 Load Controller Module featuring here was originally designed for Woodward's LS-5 Series, and as such seems to make use of a standard series of hardware components, including its:
- 12 front-included pushbuttons
- USB port
- Vented plastic chassis
- 2 interior terminal strips
One of the 8440-1947 Load Controller Module's terminal strips is much shorter than the other, offering nine terminal connections to the larger strip's 19 terminal points. The chassis of the 8440-1947 Load Controller Module is vented for natural air circulation.
8440-1947 Load Controller Module I/Os
Some of the more specifically-defined inputs and outputs possible for the 8440-1947 Load Controller Module would have to include its:
- 8 Discrete Inputs
- 6 Relay Outputs
- 1 CAN Interface
- 1 RS-485 Interface
