About the 8440-1946
The 8440-1946 Circuit Breaker Control and Protection Module here was originally manufactured for Woodward's LS-5 Series, and as such exhibits a number of basic hardware essentials for its function, including its:
- Set of 9 labeled LEDs
- 3 terminal strips
- Slot-based backplane mounting
- Singular Ethernet port
The sole Ethernet port in the assembly of this 8440-1946 Circuit Breaker Control and Protection Module has been labeled "DPC" in allusion to a possible connector. The 8440-1946 Circuit Breaker Control and Protection Module's metal chassis is vented.
8440-1946 Module Functionality
Original manual materials for the 8440-1946 Circuit Breaker Control and Protection Module details some of its intended functions. These include its:
- Automatic and manual operation
- Slip synchronization
- Phase matching
- Sync vector group adjustment
- Dead bus closure direction configuration
