The IS220PSVOH1B is a Servo Control Module from the Mark VIe Series manufactured by GE Energy

New Surplus Factory Package
$5985
SKU: 75MVMVCS1
3 Year Warranty:
Order Before 3PM EST
Rush Available
5 in Stock
New Surplus AX Control Package
$4760
SKU: 75MVMVCS2
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Reconditioned
SKU: 75MVMVCS3
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Repair
$1765
SKU: 75MVMVCS4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the IS220PSVOH1B

The IS220PSVOH1B is a Servo Control Module from the Mark VIe Series. This module was manufactured by GE Energy. The IS220PSVOH1B provides an electrical interface between one or two I/O Ethernet networks and a TSVO servo terminal board. There are several inputs and outputs that the IS220PSVOH1B accepts. These are:

  • 2 servo valve current outputs
  • 8 LVDT inputs
  • 2 pulse rate inputs
IS220PSVOH1B Specifications

Input to the IS220PSVOH1B is through dual RJ45 Ethernet connectors and 28 V dc power is provided through the terminal board. Output is through a DC-62 pin connector that connects directly to the terminal board connector.

The IS220PSVOH1B also uses the adjacent WSVO servo driver module to handle 2 servo valve position loops, with up to 5 servo valve output currents from 10-120 mA dc. The module also supplies LVDT excitation.

The IS220PSVOH1B includes diagnostic LEDs on its face to allow users to know the status of the module. There is also an infrared port that allows for local diagnostic serial communications.

IS220PSVOH1B Technical Specifications

Part Number IS220PSVOH1B
Product Type Servo Control Module
Manufacturer General Electric
Series Mark VIe
External Power Requirement 28 V dc
Outputs Included 2 Total Outputs
LVDT-Type Inputs 8 LVDT Inputs
Pulse Rate Inputs 2 Inputs
Sister Product IS220PSVOH1A
Base Coating Complete Conformal
Country of Manufacture/Origin United States
Shipping Weight 5 lbs
Shipping Dimensions 12x12x12 Inches

Frequently Asked Questions about IS220PSVOH1B

What terminal board does the IS220PSVOH1B connect with?

The IS220PSVOH1B connects with the TSVOH1B terminal board.

How are Ethernet connections identified on the IS220PSVOH1B?

A green LED will light up when there is a valid Ethernet connection.

Reviews For IS220PSVOH1B

Internal Review
(5.0)

The IS220PSVOH1B can be used in both simplex and TMR control modes, making this a five star product. The TMR mode requires three PSVO packs, which allows for more inputs and outputs. The IS220PSVOH1B has a distinct I/O board that is specific to the servo control function. - AX Control Lead Technician
