The IS220PRTDH1B is a Resistance Temperature Device Input Pack from the Mark VIe Series by GE Energy

New Surplus Factory Package
$7465
SKU: 73MVMVCS1
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus AX Control Package
$6845
SKU: 73MVMVCS2
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Reconditioned
$3985
SKU: 73MVMVCS3
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Repair
$2225
SKU: 73MVMVCS4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the IS220PRTDH1B

The IS220PRTDH1B is a Resistance Temperature Device Input pack that was manufactured by GE Energy for the Mark VIe Series. The IS220PRTDH1B is designed to act as an electrical interface between one or two I/O Ethernet networks and an RTD input terminal board. The pack can accept up to eight RTD inputs.

IS220PRTDH1B Specifications

The IS220PRTDH1B contains a processor board, the BPPC, and an acquisition board that is specific to the RTD input function. Input to the IS220PRTDH1B is through its DC-37 pin connector that is connected directly to the terminal board connector. There is also a three pin power input. For output, the IS220PRTDH1B has dual RJ-45 Ethernet connectors.

There are several terminal boards that are compatible with the IS220PRTDH1B. These are:

  • TRTFH1D
  • TRTDH2D
  • SRTD

IS220PRTDH1B Technical Specifications

Part Number IS220PRTDH1B
Product Type RTD Input Module
Manufacturer GE Energy
Series Mark VIe
Terminal Boards IS200TRTDH2D, IS200SRTDH1A , or IS200SRTDH2A
Accessory Total 3 Boards
Ambient Temperature Rating -30 to + 65 °C
Base PCB Coating Conformal Coating
Ethernet Ports 2 Ports

Frequently Asked Questions about IS220PRTDH1B

Which operating modes does the IS220PRTDH1B support?

The IS220PRTDH1B only supports simplex operating modes.

How are diagnostics relayed to users on the IS220PRTDH1B?

The IS220PRTDH1B has indicator LEDs that provide visual diagnostics.

Reviews For IS220PRTDH1B

Internal Review
(5.0)

Two PRTD packs can be plugged into the TRTD board to handle 16 simplex inputs, which allows for double the amount of inputs than would be had with just a single pack. One downside of the IS220PRTDH1B is that the pack can only be used in simplex operating modes, which does not allow for dual and TMR operating options. - AX Control Lead Technician
