IS220PDIIH1B

    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures 4.93 (15) Click a star to rate this product
    Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures Varying star amount pictures
  • 4.93 (15)
  • Click a star to rate this product


The IS220PDIIH1B is an Isolated Discrete Input Module from the Mark VIe series manufactured by GE Energy

New Surplus Factory Package
SKU: 62MVMVCS1
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

New Surplus AX Control Package
SKU: 62MVMVCS2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
$8865
SKU: 62MVMVCS3
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
Repair
$2675
SKU: 62MVMVCS4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the IS220PDIIH1B

The IS220PDIIH1B is an Isolated Discrete Input Module that was manufactured by GE Energy. The module was designed for the Mark VIe series of turbine controls. The IS220PDIIH1B acts as an electrical interface between one or two I/O Ethernet networks and a point/group isolated discrete input terminal board.

IS220PDIIH1B I/O Module Specifications

The IS220PDIIH1B can accept up to 16 isolated contact inputs that can be point or group isolated, or a mix of both depending on the terminal and optional board configurations. The terminal board that the IS220PDIIH1B uses is the SDII. The IS220PDIIH1B uses a WDII optional board, which can either be the WDIIH1, WDIIH2, or WDIIH3. The IS220PDIIH1B also has a BPPC processor board in its makeup.

The IS220PDIIH1B has LEDs that allow users to see the status of the module. The following statuses are displayed on these LEDs:

  • Network
  • I/O pack
  • Contact input status

The IS220PDIIH1B accepts inputs through its dual RJ45 Ethernet connectors and a DC-37 pin connector. There is also a 3-pin power connector that is designed for 28 V dc power for the pack and the terminal board.

IS220PDIIH1B Technical Specifications

Part Number IS220PDIIH1B
Product Type Isolated Discrete Input Module
Manufacturer GE Energy
Series Mark VIe
I/O Pack Redundancy Discrete
Number of Channels 16 Channels
Terminal Board IS200SDII
GE Original Manufacture Location Domestic Manufacture

Frequently Asked Questions about IS220PDIIH1B

Does the IS220PDIIH1B have a diagnostic test to make sure that contact input excitation voltage is within range?

Yes, the IS220PDIIH1B has a variety of self diagnostic tests, including one that monitors the range of the contact input excitation voltage.

What does a red LED mean for Contact Status Indication?

A red LED signfies a line fault or invalid voltage.

Reviews For IS220PDIIH1B

Internal Review
(5.0)

The IS220PDIIH1B is a more advanced version of the IS220PDIIH1A with a better processor board in the BPPC board. The processor board is used in many other Mark VIe packs, which makes obtaining this board easier. Users can determine the voltage level of the pack based on which optional board they use with the pack. - AX Control Lead Technician
