IS220PCAAH1A
4.93 (14)
Click a star to rate this product
- 4.93 (14)
- Click a star to rate this product
The IS220PCAAH1A is a Core Analog Module from the Mark VIe series manufactured by GE Energy
* Learn More About Product Conditions
* Posted pricing available for website purchases only.
Product Conditions
New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.
New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.
Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.
About the IS220PCAAH1A
The IS220PCAAH1A is a Core Analog Module that was manufactured by GE Energy. The module was designed for the Mark VIe series, specifically for gas turbines.
The IS220PCAAH1A is designed to provide a number of the analog signal I/O that are required to operate a gas turbine. The IS220PCAAH1A works with the TCAT and TCAS terminal board that are terminal boards. There are a number of terminals that the IS220PCAAH1A has. Some of these are:
- Seismic inputs
- Thermocouple inputs
- 4-20 mA current loop I/O
- Servo coil outputs
The IS220PCAAH1A can be used in simplex, dual, and TMR systems. This module contains a processor board, a terminal board, and two application I/O boards.
There are two groups of signals on the IS220PCAAH1A. The first group is made up of signals that can be fanned from a signal input into a single, dual, or TMR PCAA module are routed through the TCAT board. The other group is made up of signals that are designed for one PCAA module and are wired to the terminals on the PCAA.
IS220PCAAH1A Technical Specifications
| Part Number | IS220PCAAH1A |
| Functional Description | Gas Turbine Core Analog I/O Board |
| Manufacturer | GE Energy |
| Series | Mark VIe |
| Primary Functional Revision | A |
| Mounting Strategy | Rack-Based Mounting |
| Base PCB Coating | Conformal Coating |
Frequently Asked Questions about IS220PCAAH1A
Is the IS220PCAAH1A compatible with other I/O packs?
How does the IS220PCAAH1A get input?
Reviews For IS220PCAAH1A
Internal Review
(5.0)The IS220PCAAH1A can be used with multiple terminal boards, which makes this a more flexible module. These boards are the TCAS and TCAT terminal boards. The IS220PCAAH1A has 120 box terminals, allowing for field device I/O connections. This enables the module to work with a variety of field devices. - AX Control Lead Technician
