The IS220PAOCH1A is an Analog Output Pack manufactured by GE Energy for the Mark VIe series.

New Surplus Factory Package
$8925
SKU: 55MVMVCS1
3 Year Warranty:
Order Before 3PM EST
Rush Available
1 in Stock
New Surplus AX Control Package
SKU: 55MVMVCS2
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned
$4475
SKU: 55MVMVCS3
3 Year Warranty:
Order Before 3PM EST
Rush Available
5 in Stock
Repair
$1985
SKU: 55MVMVCS4
3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the IS220PAOCH1A

The IS220PAOCH1A is an Analog Output pack that is designed to be used in the Mark VIe series. The IS220PAOCH1A was manufactured by GE Energy. This pack works to provide an electrical interface between one or two I/O Ethernet networks and an analog output terminal board, the TBAO.

IS220PAOCH1A LED Specifications

The IS220PAOCH1A pack has a processor board that is common to all Mark VIe distributed I/O packs and an acquisition board that is specific to the analog output function.

The IS220PAOCH1A can provide up to eight simplex 0-20mA current loop outputs. The IS220PAOCH1A also has an analog to digital converter for current feedback from the outputs. There are a variety of diagnostic LEDs on the pack. Some of these are:

  • ATTN
  • PWR
  • ENET 1
  • ENET 2

The input to the pack is supplied through dual RJ45 Ethernet connectors and a three-pin power connector. Output is supplied through a DC-37 pin connector.

IS220PAOCH1A Technical Specifications

Functional Part Number IS220PAOCH1A
Product Type Analog Output Pack
Manufacturer GE Energy
Series Mark VIe
Analog Output Current Rating 0-20 mA
Number of Channels 8 Current Output Channels
Compatibility TBAOH1C/STAOH1A
PCB Coating Conformal Coating

Frequently Asked Questions about IS220PAOCH1A

What boards is the IS220PAOCH1A compatible with?

The IS220PAOCH1A is compatible with the TBAO terminal board, the STAO board, the BPPB processor board, and the BPAO acquisition board.

Does the IS220PAOCH1A work with the DTAO board?

No, the IS220PAOCH1A does not work with the DTAO board.

Reviews For IS220PAOCH1A

Internal Review
(4.0)

The IS220PAOCH1A is not compatible with the H1A and H1B versions of the TBAO board. The lack of compatibility makes this a four star part, with the pack only being fully compatible with the H1C version of the TBAO board. - AX Control Lead Technician
