IS220PAICH2B

4.86 (14)

Click a star to rate this product

4.86 (14)
Click a star to rate this product

The IS220PAICH2B is an Analog I/O Pack from the Mark VIe Series manufactured by GE Energy

New Surplus Factory Package

SKU: 54MVMVCS1

3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

New Surplus AX Control Package

SKU: 54MVMVCS2

3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Reconditioned

SKU: 54MVMVCS3

3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

Repair

$2370

SKU: 54MVMVCS4

3 Year Warranty:

1-919-372-8413 | 1-800-991-7026

sales@axcontrol.com

* Learn More About Product Conditions
* Posted pricing available for website purchases only.

Product Conditions

New Surplus Factory Package: A completely unused product that is in the original factory package. The package may have been opened for the purpose of pictures, but the product has never been used or installed.

New Surplus AX Control Package: A completely unused product that has been removed from the original factory package. Often due to shelf wear or previous shipping, the factory package is not adequate and must be replaced with an ideal AX Control product package.

Reconditioned: All products that qualify as reconditioned have completed AX Control's thorough and detailed QA process and meet the requirements of excellent working condition and excellent cosmetic condition.

About the IS220PAICH2B

The IS220PAICH2B is an Analog I/O Pack from the Mark VIe series for turbine control. The IS220PAICH2B was manufactured by GE Energy. The IS220PAICH2B is designed to act as an interface between one or two I/O Ethernet networks and an analog input terminal board, the TBAI board.

IS220PAICH2B I/O Specifications

The IS220PAICH2B is designed to be used with a processor board and an acquisition board. The acquisition board is the BPAI board, and the processor board is the BPPB board.

The IS220PAICH2B can handle up to 10 analog inputs, with the first 8 inputs able to be configured in multiple ways. These configurations are:

+/- 5V input
+/- 10V input
0-20 mA current loop input

The final 2 inputs can be configured to +/- 1 mA or 0-20 mA current inputs.

This pack also has 2 outputs, the first of which can have a current rating of 0-200 mA.

IS220PAICH2B Technical Specifications

Functional Part Number	IS220PAICH2B
Manufacturer	General Electric
Series	Mark VIe
Functional Description	IS220PAICH2B Analog I/O Pack
Input and Output Signal Type	Analog I/O
Mark VIe/S Revisions Applied	B-Rated Functional Revision
mA Out	200 mA Out
Warranty	Three Year Warranty

Frequently Asked Questions about IS220PAICH2B

Which version of the TBAI board can the IS220PAICH2B be mounted onto?

The IS220PAICH2B can be mounted for full compatibility with the H1C version of the TBAI board.

How does the IS220PAICH2B have capabilities for an output of 200mA?

The IS220PAICH2B has extra hardware which gives this pack the expanded capability.

Reviews For IS220PAICH2B

Internal Review

(5.0)

The IS220PAICH2B is a better pack than the PAICH1 pack given this pack has the expanded capabilities for 0-200mA output. The PAICH1A only allows for 0-20mA outputs. Another advantage of the IS220PAICH2B is its provided diagnostic LEDs that allow users to know the status of the pack. - AX Control Lead Technician
