About the IS220PAICH2A

The IS220PAICH2A was manufactured by GE Energy for the Mark VIe Turbine Control System Series. The IS220PAICH2A is an Analog I/O Pack that works with a variety of different boards from the Mark VIe series.

Contextualized IS220PAICH2A Hardware

The IS220PAICH2A acts as an electrical interface between one or two I/O Ethernet networks and an analog input terminal board. The IS220PAICH2A features a processor board and an acquisition board. The acquisition board is specific to the analog input function, whereas the processor board is standard for all Mark VIe distributed I/O packs.

The IS220PAICH2A can handle up to 10 analog inputs, with the first 8 able to be configured to +/- 5V or 10V inputs, or 0-20 mA current loop inputs. The final two inputs can be configured to +/- 1 mA or 0-20 mA current inputs.

Input is received through the RJ45 Ethernet connectors and a three pin power input. Output is through a DC 37 pin connector that is connected to the terminal board connector.

The IS220PAICH2A is equipped with several visual diagnostic LEDs. Some of these LEDs are:

  • PWR
  • ATTN
  • LINK

There is also an infrared port that allows for local diagnostic serial communications.

IS220PAICH2A Technical Specifications

Functional Part Number IS220PAICH2A
Manufacturer GE Energy
Series Mark VIe
Functional Description IS220PAICH2A Analog I/O Pack
mA Out Rating 200 mA Out
Input or Output I/O; Analog
Mark Series Individual Grouping Group 2 Device
Base Circuitry Protection Conformal Coat (Sprayed)

Frequently Asked Questions about IS220PAICH2A

What is the IS220PAICH2A pack's unique Mark Series product output rating?

The IS220PAICH2A has a 0-200mA output rating.

What processor board does the IS220PAICH2A work with?

The IS220PAICH2A works with the BPPB processor board.
